FURTHER BOWSER SPECIFICATIONS
CHASSIS: Constructed from 5mm pressed steel section fully welded with a front mounting plate and 100 x 50 RSC ‘A’ frame drawbar.
AXLE/SUSPENSION: Single Knott-Avonride 3000kg torsion beam axle fitted with 300 x 60 auto reverse brakes.
WHEELS AND TYRES: 2 no. 235 /85 x 16 x 12 ply radial tyres on 5 stud 61/2” pcd rims.
COUPLING: Knott-Avonride 3000kg capacity posibrake over run auto reverse coupling c/w breakaway cable, spring assisted handbrake lever, fitted with 40mm eye or 50mm ball.
TANK: Polyethylene moulded tank, elliptical in section, with internal anti surge baffle & fitted with a 22” lockable outer hinged manlid cover, inner sealed vented manlid. 2” front draw off, 2 rear outlet connections. Tank secured to chassis with 2 stainless steel straps.
ANCILLARY EQUIPMENT: moulded mudguards, mud flaps, front telescopic jockey wheel, Side reflectors, & front markers, full road lighting c/w 13 pin plug, optional extra 7 pin adapter, available on request.
FINISH: Polyethylene tank in Black. Chassis painted with double corrosive resistant protection as standard.
DIMENSIONS: (approximate)
- Width: 1.955 m (77”)
- Length: 4.527 m (178½”)
- Height: 1620 m (64”)
- Towing Height: (level) 450 mm
- Unladen weight: 796 kg
- Gross Laden weight: 1925 kg
